- Features
• Perfect for recycling/pelletizing LDPE, HDPE, LLDPE, HDPE Film Waste and Granules
• Features Double Stage Extrusion to process film waste with larger printed surface as well as film waste with more humidity and water
• Granulator and conveyor can be added and combined into a complete recycling line
• Suitable for recycling materials with heavy printed surface and water content
• Die face cutting type
• Screw diameter available from 65 mm ~ 150 mm
- Specifications
| MODEL | TR-65V+2 | TR-85V+2 | TR-100V+2 | TR-120V+2 | TR-150V+2 |
| MATERIAL | LDPE , LLDPE , HDPE , PP , ABS , PS | ||||
| EXTRUSION OUTPUT | PE 100 – 120 KG/HR | PE 180 – 250 KG/HR | PE 250 – 350 KG/HR | PE 400 – 550 KG/HR | PE 600 – 800 KG/HR |
| PP 80 – 120 KG/HR | PP 120 – 180 KG/HR | PP 200 – 250 KG/HR | PP 300 – 450 KG/HR | PP 500 – 700 KG/HR | |
| EXTRUDER | VENT(V) | VENT(V) | VENT(V) | VENT(V) | VENT(V) |
| SCREW | 65 | 85 | 100 | 120 | 150 |
| L/D | 30 | 30 | 30 | 30 | 30 |
| BARREL HEATING ZONE | 3 | 4 | 6 | 6 | 6 |
| DRIVING MOTOR | 40 HP | 60 HP | 100 HP | 125 HP | 26 KW | 32 KW | 48 KW | 64 KW | 75 KW |
| SECOND EXTRUDER | VENT(V) | VENT(V) | VENT(V) | VENT(V) | VENT(V) |
| SCREW | 65 | 85 | 100 | 120 | 150 |
| L/D | 10 | 10 | 10 | 10 | 10 |
| BARREL HEATING ZONE | 2 | 2 | 2 | 3 | 3 |
| DRIVING MOTOR | 15 HP | 25 HP | 40 HP | 50 HP | 100 HP |
| HEATER CAPACITY | 8 KW | 10 KW | 12 KW | 16 KW | 20 KW |
| SCREEN CHANGER | HYDRAULIC SYSTEM WITH PRESSURE GAUGE NON-STOP CONTINUOUS TYPE | ||||
| FILTER DIAMERER | 150 MM | 200 MM | 200 MM | 220 MM | 280 MM |
| DRIVING MOTOR | 3 HP | 3 HP | 3 HP | 5 HP | 5 HP |
| DIE HEAD CUTTER DEVICE | |||||
| HEATING ZONE | 2 | 2 | 2 | 2 | 2 |
| HEATING CAPACITY | 4 KW | 6 KW | 8 KW | 9 KW | 10 KW |
| DIE HOLES | 16 & 24 | 20 & 40 | 40 & 80 | 50 & 100 | 70 & 100 |
| HOLE DIAMETER | 2.5 MM & 2.8 MM | 2.5 MM & 2.8 MM | 2.5 MM & 2.8 MM | 2.5 MM & 2.8 MM | 2.5 MM & 3.5 MM |
| CUTTERS USED | 1 – 4 | 1 – 4 | 1 – 4 | 1 – 4 | 1 – 4 |
| CUTTER DRIVE | 2 HP | 2 HP | 2 HP | 3 HP | 3 HP |
| COOLING WATER PUMP | 2 HP | 3 HP | 3 HP | 5 HP | 7.5 HP |
| VIBRRATION SCREEN &WATER BATH | |||||
| VIBRATION MOTOR | 1/4 HP × 2 | 1/3 HP × 2 | 1/2 HP × 2 | 1/2 HP × 2 | 1/2 HP × 4 |
| VIBRATION SIZE | 350 × 1700 MM | 350 × 1700 MM | 400 × 1800 MM | 500 × 2000 MM | 750 × 5000 MM |
| PELLET CONVEYOR | |||||
| BLOWER MOTOR | 3 HP | 3 HP | 5 HP | 5 HP | 7.5 HP |
| CONVEYING CAPACITY | 300 KG/HR | 300 KG/HR | 600 KG/HR | 600 KG/HR | 800 KG/HR |
| STORAGE TANK | 1000 KG | 1000 KG | 1000 KG | 1000 KG | 1000 KG |
| OPTIONAL | TWIN CYLINDER TYPE SCREEN CHANGER. VACUUM PUMP | ||||
SPECIFICATION FOR REFERENCE ONLY
WE RESERVE THE RIGHT TO ALTER OR AMEND THE DESIGN
